Power Electronics Components Characteristics Trainer

Mine  Power Electronics Components Characteristics Trainer is remarkable and frequently used laboratory equipment which is designed to explain fundamentals and working of DIAC, TRIAC, SCR, IGBT, MOSFET & JEET.
By using this product student can understand the basic concept of DIAC, TRIAC, SCR, IGBT, MOSFET & JEET which are the basic devices used in Power Electronics.
V-I Characteristics can be drawn by the student which helps them to understand the behavior of these devices easily.

This product has suitable in-built power supply and on-board resistor of different values. Breadboard area allows construction of circuits using external components along with on – board resources.
